The Latest Model (ABM-832A2) Steel Rule Auto Bender Machine with Perforation included functions：Bending,Bridge,Perforation,Lipping and Cutting. Supported steel rule thickness 0.71,1.05mm(2pt&3pt),height 8-32mm. China Adewo has been successful for many domestic and foreign die making&printing companies to provide advanced Auto Bender Machines, cost effective,technical support and excellent after sales service.
1.Bending and cutting in one,more safety of cutting. High efficiency of bending and cutting.
2.Multi-Punch tool for choice:Lipping, Mold Cut, Bridge, Hole or Perforation, independent tool, easy toreplace.
3.Double clamps,screw guide feeding continuously, improves work efficiency.
4.Smart software,easy to operate, multi language available.
|
Supported rule thickness(mm) |
0.45/0.53/0.71/1.05mm (1/1.5/2/3pt) |
|
Supported rule height(mm) |
8-32mm |
|
Bridge height |
18mm&15mm adjustable |
|
Bridge width |
Over 5mm any sizes available. (Can be customized) |
|
Front Min. bending size |
1.5MM |
|
Back Min. cutting size |
1.0MM |
|
Feeding precision |
±0.03mm |
|
Bending flatness |
0.2mm |
|
Basic Functions |
Bending,Bridge,Lipping,Cutting |
|
Optional Functions |
Perforation/Hole |
|
Optimal pattern format |
DXF,DWG |
|
Air supply |
0.4-0.8MPa |
|
Power supply |
Single Phase AC220V,13.6A,50-60Hz |
|
Machine total power |
3KW |
|
Weight |
528KG |
|
Overall dimension |
2850x800x1600mm(LxWxH) |
|
H.S. Code |
8462230000 |
We provide remote support to customers all over the world.
Our technical service is always available at services@china-adewo.com
